Flow control valves - ATOS
LIDAS, LIDA, LIDO, LIDB, LIDR, LIDEW, LIDBH, LIQV, LIDD, LIM, LIR, LIC, LID
LIM, LIR, LIC - Modular pressure control valves in ISO cartridge design specific for relief, reducing or compensator functions. Features:
  • ISO 7368 sizes from 16 to 80
  • Max flow: up to 5000 l/min with Δp = 5 bar
  • Max pressure: 420 bar
LIQV, LIDD - Flow control valves with manual setting for fine regulation or with stroke limiter. Features:
  • ISO 7368 sizes from 16 to 63
  • Max flow: up to 3500 l/min with Δp = 6 bar
  • Max pressure: 350 bar
Ask about product
LIDEW, LIDBH - Modular cartridge valves, directional control, with solenoid valve and optional shuttle valve for pilot selection. Features:
  • ISO 7368 sizes from 16 to 100
  • Max flow: up to 8000 l/min with Δp = 6 bar
  • Max pressure: 350 bar

LIDA, LIDO, LIDB, LIDR - Modular cartridge valves for a check function. Normally closed and normally open versions are available. Features:
  • ISO 7368 sizes from 16 to 100
  • Max flow: up to 8000 l/min with Δp = 6 bar
  • Max pressure: 350 bar

LIDAS - On-off active cartridges valves, 2-way, designed for mounting in manifold blocks and providing the leak-free shut-off function of the hydraulic line. Features:
  • ISO 7368 sizes from 16 to 50
  • Max flow: up to 2000 l/min with Δp = 5 bar
  • Max pressure: 420 bar

For more information see technical data below.
  • Technical data: Modular pressure control valves LIM, LIR, LIC
  • Technical data: Flow control valves LIQV, LIDD
  • Technical data: Modular cartridge valves - directional control LIDEW, LIDBH
  • Technical data: Modular cartridge valves LIDA, LIDO, LIDB, LIDR
  • Technical data: On-off active cartridges valves LIDAS
